Regional, Urban, On/Off-Road, Drive/All-Position Tire
The Toyo M655 has been created to meet the demands of the modern mixed service commercial customer.
The M655 was designed and tested year round, in harsh Canadian conditions, to ensure your fleet keeps moving. Maximizing uptime, to save you money.
APPLICATION | RECOMMENDED | SUITABLE |
REGIONAL | DRIVE | - - |
URBAN | DRIVE | - - |
ON/OFF ROAD | DRIVE | STEER |
![]() ![]() ![]() ![]() ![]() |
View all : "Drive-axle Position Tires"
Does this tire fit your vehicle?
Features and Benefits
Sizes & Specifications
Warranty Details
Replace
- E-balance casing technology increases mileage performance by optimizing the footprint of the tread
- Wider tread width for even load distribution, improved stability, and excellent profile retention.
- Multi-wave sipes ensures traction in slippery conditions.

- All-weather traction.
- Studdable for extreme winter conditions.

- Saddle notch and stone ejector combination designed to enhance block stiffness and keep the tread free of stones and debris.
- A special tread compound and aggressive sidewall protector improves durability.
Tire Size | Load/Speed | Product Code | Approved Rim Width Range (inch) | Overall Diameter (inch) | Overall Width (inch) | Sidewall | Tread Depth (1/32") | Revs/km | Max Load Single (lbs.) | Max Pressure Single (psi) | Rim Diameter |
---|---|---|---|---|---|---|---|---|---|---|---|
225/70R19.5 | 128/126N | 556640 | 6.00-(6.75)-6.75 | 32.3 | 8.5 | BL | 20 | 400 | 3970/3750 | 110/110 | 19.5 |
245/70R19.5 | 136/134N | 556650 | 6.75-(7.50)-7.50 | 33.5 | 9.9 | BL | 21 | 386 | 4940/4675 | 120/120 | 19.5 |
265/70R19.5 | 140/138L | 111390 | 7.5-(7.50)-8.25 | 34.5 | 10.0 | BL | 20 | 374 | 5510/5205 | 112/112 | 19.5 |
265/70R19.5 | 140/138N | 111300 | 7.50-(7.50)-8.25 | 34.5 | 10.0 | BL | 20 | 374 | 5510/5205 | 112/112 | 19.5 |
Tire Size | Load/Speed | Product Code | Approved Rim Width Range (inch) | Overall Diameter (inch) | Overall Width (inch) | Sidewall | Tread Depth (1/32") | Revs/km | Max Load Single (lbs.) | Max Pressure Single (psi) | Rim Diameter |
---|---|---|---|---|---|---|---|---|---|---|---|
11R22.5 | 146/143L | 556790 | 7.50-(8.25)-8.25 | 42.1 | 11.1 | BL | 28 | 307 | 6610/6005 | 120/120 | 22.5 |
Tire Size | Load/Speed | Product Code | Approved Rim Width Range (inch) | Overall Diameter (inch) | Overall Width (inch) | Sidewall | Tread Depth (1/32") | Revs/km | Max Load Single (lbs.) | Max Pressure Single (psi) | Rim Diameter |
---|---|---|---|---|---|---|---|---|---|---|---|
11R24.5 | 149/146L | 556800 | 7.50-(8.25)-8.25 | 44.0 | 11.1 | BL | 28 | 293 | 7160/6610 | 120/120 | 24.5 |
TRUCK TIRE LIMITED WARRANTY AND CASING POLICY
Limited Warranty Manual - Medium Truck Tires
The Toyo M655 replaces the following tires:
Dunlop SP 831
Goodyear Workhorse MSA
Goodyear Workhorse MSD
