Super Regional All Position
The M171+ super regional steer tire complements the M671A+ super regional drive tire. Working together, these tires are specifically designed to provide long wear, exceptional fuel efficiency, and superior traction, within demanding 500-mile radius operations. Toyo’s Nano Balance Technology results in exceptional fuel efficiency and resistance to irregular wear. An advanced design reduces strain at the bead area and belt edge to deliver a long life.
APPLICATION | RECOMMENDED | SUITABLE |
LONG-HAUL | STEER | DRIVE,TRAILER |
View all : "All Position Tires"
Does this tire fit your vehicle?
Features and Benefits
Sizes & Specifications
Warranty Details
Replace
- E-balance technology retains the tread profile while reducing strain at the bead area and belt edge.
- Stone ejectors prevent casing damage.
- Steel chafer bead improves durability and retreadability.
- Nano Balance Technology increases fuel efficiency and provides long, even wear.
- An advanced tread design provides good traction and a smooth ride.
- A wide belt package minimizes the growth of the tread profile and maintains a flatter tread radius.
- Improved Tread Compound.
- Maximizes removal miles while maintaining low rolling resistance and traction.
Tire Size | Load/Speed | Product Code | Approved Rim Width Range (inch) | Overall Diameter (inch) | Overall Width (inch) | Sidewall | Tread Depth (1/32") | Revs/km | Max Load Single (lbs.) | Max Pressure Single (psi) | Rim Diameter |
---|---|---|---|---|---|---|---|---|---|---|---|
295/75R22.5 | 144/141L | 520060 | 8.25-(8.25)-9.0 | 40.1 | 11.1 | BL | 20 | 321 | 6175/5675 | 110/110 | 22.5 |
295/75R22.5 | 149/146L | 520050 | 8.25-(8.25)-9.0 | 40.1 | 11.1 | BL | 20 | 321 | 7160/6610 | 123/123 | 22.5 |
11R22.5 | 144/142L | 520080 | 7.5-(8.25)-8.25 | 41.5 | 11.1 | BL | 20 | 311 | 6175/5840 | 105/105 | 22.5 |
11R22.5 | 146/143L | 520070 | 7.5-(8.25)-8.25 | 41.5 | 11.1 | BL | 20 | 311 | 6610/6005 | 120/120 | 22.5 |
